CS-09 Ribbon Fiber Thermal Stripper
The CS-09 is a ribbon fiber optic thermal stripper designed for preparing silicon glass ribbon fibers before mass fusion splicing, with a dedicated fiber fixture for secure and consistent stripping.
- For ribbon fiber preparation before mass fusion splicing
- Strips 1–12 core silicon glass ribbon fibers
- Four selectable heating temperatures: 90°C / 100°C / 110°C / 140°C
- Fast heating: approx. 4 s in Normal Mode
- Low pulling force needed for stripping
- Ergonomic design
- Dedicated fixture holds ribbon fibers securely
- Power saving mode for longer field operation
- USB Type-C charging, approx. 660 stripping operations per full charge
- Replaceable blade set for long service life
- Supplied with: Thermal Stripper x1, USB Type-C cable x1, Brush x1, Portable Bag x1, Packing box x1
Specifications
Technical data for the CS-09 Ribbon Fiber Thermal Stripper. Need a full datasheet or help comparing models? Contact our sales team.
| Model | CS-09 |
|---|---|
| Fiber material | Silicon Glass Ribbon Fiber |
| Applicable fiber | 1 to 12 cores |
| Cladding diameter | 125 μm |
| Coating diameter | 200 ~ 400 μm |
| Stripping length | Up to 30 mm |
| Power mode | Normal Mode / Power Save Mode |
| Temperature setting | Approx. 90°C / 100°C / 110°C / 140°C |
| Heating time | Normal Mode: Approx. 4 s / Power Save Mode: Approx. 5 s |
| Battery capacity | Lithium ion battery 7.4 V 2000 mAh |
| Endurance | A single full charge can be continuously stripped for approx. 660 times |
| Power supply | USB Type-C (5V–20V, Max. 20W) |
| Operating condition | Temperature: -10°C ~ 40°C / Humidity: 0% ~ 95% |
| Dimensions | 132L x 48W x 32H (mm) |
| Weight | 365 g |
